Main Unit

1. Machine Type
2. A3 Monochrome Laser Multifunctional
3. Core Functions
4. Print, Copy, Scan, Send and Optional Fax
5. Processor Speed
6. 1.6GHz Dual Core Processor
7. Control Panel
8. Standard: 7 inch TFT LCD WVGA Colour Touch panel
9. Memory
10. Standard: 2.0GB RAM
11. Storage
12. Standard: 64GB eMMC
13. Optional: 256GB SSD
14. Interface Connection
15. NETWORK Standard:
16. 1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), Wi-Fi Direct Connection OTHERS Standard:
17. USB 2.0 (Host) x2, USB 2.0 (Device) x1
18. Paper Input (Standard)
19. Paper Input (Standard)
20. Paper Supply Capacity (A4, 80 gsm)
21. Standard: 1,200 sheets
22. Maximum: 2,300 sheets (with Cassette Feeding Unit-AW1)
23. Paper Output Capacity (A4, 80 gsm)
24. Standard: 250 sheets
25. Maximum: 645 sheets (with Inner Finisher-L1 and Copy Tray-T2)
26. Finishing Capabilities
27. Collate, Group, Offset, Staple, Hole Punch, Eco Staple, Staple On Demand¹
28. Supported Media Types
29. Main Body Cassette (Upper/Lower):
30. Thin, Plain, Recycled, Color, Heavy, Bond, Pre-Punched, Letterhead, PostCardMulti-purpose Tray:
31. Thin, Plain, Recycled, Color, Heavy², Bond, Pre-Punched, Letterhead, PostCard, Labels, Coated, Tracing
32. Supported Media Sizes
33. Upper Cassette: Standard size: A4, A5, A5R, A6R, B5
34. Custom Size: 105.0 x 148.0 mm to 297.0 x 215.9 mmLower Cassette: Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, COM 10 No. 10*, Monarch*, DL*
35. Custom Size: 105 x 148 mm to 304.8 x 457.2 mm*Requires Envelope Attachment A (std)
36.

37. Supported Media Weights
38. Main Body Cassette (Upper/Lower): 52 to 256 gsm Multi-purpose tray: 52³ to 300 gsm Duplex: 52 to 220 gsm
39. Warm-up Time
40. 4 Seconds or Less⁴ From Sleep Mode: 10 seconds or less
41. From Power On: 10 Seconds or Less⁵
42. Dimensions (W x D x H)
43. 565 x 687 x 891 mm
44. Installation Space (W x D)
45. 1,286 x 1,116 mm (with DADF-BA1 + Inner Finisher tray max extended + Copy Tray-T2 max extended + paper cassette opened）
46. Weight
47. Approx. 66 kg
